Processor
The Dell PowerEdge T350 Tower Server supports a single processor with the following options:
- One Intel® Xeon® E-2300 Series processor with up to 8 cores.
- One Intel® Pentium® processor with up to 2 cores.
Operating System
The PowerEdge T350 supports several operating systems and virtualization platforms, including:
- Canonical Ubuntu Server LTS
- Microsoft Windows Server with Hyper-V
- SUSE Linux Enterprise Server
- Red Hat Enterprise Linux
- VMware ESXi*
*VMware ESXi support is available from December 2021.
Chipset
The server is powered by the Intel C256 Series chipset.
Memory
The PowerEdge T350 provides flexible DDR4 memory configurations.
DIMM Speed
- Up to 3200 MT/s.
- When using an Intel Pentium processor, the maximum supported memory speed is 2666 MT/s.
Memory Type
- UDIMM
Memory Module Slots
- 4 DDR4 DIMM slots
Maximum RAM
- Up to 128 GB UDIMM
Storage
The Dell PowerEdge T350 provides multiple front-bay storage configurations:
- Up to 4 x 3.5-inch SAS/SATA HDD or SSD drives with a maximum capacity of 64 TB.
- Up to 8 x 3.5-inch SAS/SATA HDD or SSD drives with a maximum capacity of 128 TB.
The system also supports 2.5-inch drives installed in 3.5-inch hybrid drive carriers.
Storage Controllers
Internal Controllers
Available internal storage controllers include:
- PERC H755
- PERC H345
- HBA355i
External Controllers
- HBA355e
Software RAID
- S150
Internal Boot
Internal boot options include:
- Boot Optimized Storage Subsystem (BOSS-S2) with hardware RAID and 2 x M.2 SSDs available in 240 GB or 480 GB capacities.
- Internal Dual SD Module.
- Internal USB 3.0.
Security
The PowerEdge T350 includes a range of built-in security capabilities, including:
- Cryptographically signed firmware
- Secure Boot
- Secure Erase
- Silicon Root of Trust
- System Lockdown, requiring iDRAC9 Enterprise or Datacenter
- TPM 1.2/2.0 FIPS
- CC-TCG certification
- TPM 2.0 China NationZ
Management
Embedded and At-the-Server Management
The Dell PowerEdge T350 supports:
- iDRAC9
- iDRAC Direct
- iDRAC RESTful API with Redfish
- iDRAC Service Module
Management Consoles
Available management consoles include:
- OpenManage Enterprise
- OpenManage Power Manager Plugin
- OpenManage SupportAssist Plugin
- OpenManage Update Manager Plugin
Mobile Management
- OpenManage Mobile
Management Tools
Supported management tools include:
- IPMI
- OpenManage Server Administrator
- OpenManage Storage Services
- RACADM CLI
- System Update Utility
- Update Catalogs
OpenManage Integrations
The server supports integration with:
- BMC Truesight
- Microsoft System Center
- Red Hat Ansible Modules
- VMware vCenter
- VMware vRealize Operations Manager
OpenManage Connections
Supported connections include:
- IBM Tivoli Netcool/OMNIbus
- IBM Tivoli Network Manager IP Edition
- Micro Focus Operations Manager
- Nagios Core
- Nagios XI
Power Supplies
The Dell PowerEdge T350 supports several power supply options:
- 450 W Bronze cabled AC, 100–240 V
- 600 W Platinum AC, 100–240 V
- 600 W DC, 240 V
- 700 W Titanium AC, 100–240 V
- 700 W DC, 240 V
Hot-swap power supplies with a full redundancy option are also supported.
Ports and Connectivity
Network Options
- 2 x 1 GbE LOM
Front Ports
- 1 x iDRAC Direct Micro-AB USB port
- 1 x USB 3.0 port
Rear Ports
- 5 x USB 2.0 ports
- 1 x USB 3.0 port
- 1 x Serial port
- 1 x dedicated iDRAC port
- 1 x VGA port
Internal Ports
- 1 x optional USB 3.0 port
PCIe Expansion Slots
The PowerEdge T350 provides four PCIe expansion slots:
- 2 x Gen 4 PCIe slots
- 2 x Gen 3 PCIe slots
Video Card
- 1 x VGA
Chassis
Fan
- One fan
Bezel
The server supports:
- Optional LCD bezel
- Security bezel
Form Factor
The Dell PowerEdge T350 is designed as a 4.5U Tower Server.
Dimensions and Weight
Height
- 369.5 mm (14.54 inches)
Width
- 175 mm (6.88 inches)
Depth
- 581.12 mm (22.87 inches) with bezel
Weight
- 25.34 kg (55.86 lbs.)
Rack Support
The Dell PowerEdge T350 is optimized to fit racks that comply with the EIA-310 specification. Dell does not provide dedicated rails specifically for this platform.
