Product Description
Processor
Up to two 3rd Generation Intel Xeon Scalable processors with up to 24 cores per processor
Memory
• 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 2933 MT/s
• Supports registered ECC DDR4 DIMMs only
Storage controllers
• Internal Controllers: PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150
• Internal Boot: Internal Dual SD Module, USB, Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2x M.2 SSDs
• External PERC (RAID): PERC H840
• External HBA (non-RAID): HBA355e
Drive
Bays Front bays:
• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB
• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB
• Up to 8 x 2.5-inch SAS/SATA (HDD) max 61.44 TB
Power Supplies
• 600W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant
• 800W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant
• 1100W -48Vdc hot swap redundant (CAUTION: only works with -48Vdc to -60Vdc power input)
Cooling Options
Air cooling
Fans
• Standard (STD) fans
• Up to five cabled fans
Dimensions
• Height – 86.8 mm (3.41 inches)
• Width – 482 mm (18.97 inches)
• Depth – 721.69 mm (28.72 inches) with bezel
685.78 mm (27.00 inches) without bezel
Form Factor
2U rack server
Embedded Management
• iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Module
• Quick Sync 2 wireless module
Bezel Optional
LCD bezel or security bezel
OpenManage Software
• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin
Mobility
OpenManage Mobile
Integrations and Connections
OpenManage Integrations
• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager
OpenManage Connections
• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI
Security
• Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC
2 x 1 GbE LOM
Network Options
1 x OCP 3.0 (optional)
GPU Options
Not supported
Ports
Front Ports
• 1 x Dedicated iDRAC (Micro-AB USB) port
• 1 x USB 2.0
• 1 x VGA
Rear Ports
• 1 x USB 2.0
• 1 x Serial (optional)
• 1 x iDRAC ethernet port
• 1 x USB 3.0
• 1 x VGA
Internal Ports
• 1 x USB 3.0 (optional)
PCIe
3 x PCIe Gen4 slots + 1 x PCIe Gen3 slot
• 3 x16 Gen4 low profile
• 1 x8 Gen3 (x4 lane) low profile
Operating System and Hypervisors
• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi
